Sumo

Coming 2022
Rating:
80 % of 100
$3,150.00
Assembly Options Professionally assembled by your local dealer, or DIY the assembly - its up to you!
Financing Available Buy Now, Pay Later with Klarna. We’ve partnered with Klarna to offer flexible payment options to pay over time.
30 Day Returns Our love your ride guarantee – if you’re not 100% happy with your bike, we’re not happy either. Click here for more details
Frame Warranty Covered for at least 5 years! Check out the details to see if your bike qualifies for longer.
Brakes
Hydraulic disc
Tire Size
26"x4.0"
Frame material
Aluminum

The Sumo electric fat bike is always up for full sized fun whether plowing through the snow or cruising your favorite sandy beach. The Bosch Active Line Plus mid-motor packs best-in-class power to keep you rolling wherever your adventure takes you and the oversized 4-inch tires bowl over soft surfaces and technical terrain like a steamroller. The fully formed aluminum alloy frame and fork have plenty of cargo mounts to carry heavy loads so you can pack everything you need for your next outing. Go big or go home!

Print Catalog Print Catalog
  • Frame Hydroformed Aluminum Alloy 6061 T6, Trail Performance Geometry
  • Fork Fat technical formed alloy , 6061 T6, Multi Cargo Mounts
  • Headset Integrated, Sealed Bearing
  • Cranks Forged Alloy for Bosch System
  • Sprocket Forged Spider, 36 tooth w/ chainguard, steel
  • Rear Derailleur Shimano Acera M360, SGS
  • Shifter Shimano Acera M360, 8 Speed
  • Cogset Shimano Wide Range , 11-34 8 Speed
  • Chain KMC x8 Ebike Specific
  • Front Hub Formula, Sealed Bearing, Thru Axle, 150mm
  • Rear Hub Formula, Sealed Bearing, Thru Axle, 197mm
  • Spokes Stainless
  • Rims 26",75 mm ID, Disc Specific
  • Tires Vee Rubber Mission, 26X4.0"
  • Brake Levers Tektro M275 2 Finger
  • Pedals Alloy, sealed bearing
  • Handlebar IZIP Aluminum Alloy
  • Grips IZIP Ergo Comfort Control
  • Stem IZIP Aluminum Alloy, 3d forged
  • Seat IZIP Custom Ergo Performance
  • Seatpost IZIP Aluminum Alloy, forged head
  • Battery Bosch Powerpack 400Wh, DT Mount.
  • Charger Bosch 2A
  • Motor Bosch Active Line Plus, 50Nm Torque, 20 mph
  • Display Bosch Purion Performance Line
  • Range Estimated 30mi/48km to 50mi/80km
  • Brakes Tektro M275, Hydraulic 180mm rotors
  • Product ID 4589

* Specifications are subject to change without notice

Frame Size MD Fits 5'6" - 5'9" LG Fits 5'9" - 6'
Rider Height - -
Bike Stand Over Height 743.0 mm 749.0 mm
Bike Seat Tube Length 430.0 mm 480.0 mm
Bike Top Tube Length 580.0 mm 605.0 mm
Bike Head Tube Length 115.0 mm 125.0 mm
Bike Head Angle 69.0 ° 69.0 °
Bike Seat Angle 73.0 ° 73.0 °
Bike Wheel Base 1148.0 mm 1173.0 mm
Bike Chain Stay Length 500.0 mm 500.0 mm
Bike Fork Offset 45.0 mm 45.0 mm
Bike Bb Drop 60.0 mm 60.0 mm
Bike Stack 595.0 mm 604.0 mm
Bike Reach 398.0 mm 420.0 mm
Bike Fork Length 475 mm 475 mm
Add Your Review
How Do You Rate This Product?

There are so many factors that determine your eBike’s range: the size of your battery, the level of motor assist you select, and how much weight you are carrying. Going uphill uses more battery than a flat trail.

To help you figure out the most accurate range estimate for your eBike, please try using Bosch’s range finder tool.
